5MP 5X Zoom 4G PTZ IP CCTV Camera With Night Vision
Features :
2.5 Inch Super Mini Size Case PTZ Dome 4G IP Camera
Support HD 5MP High Quality Resolution
Support TF/Micro SD Card, up to 128G(Don’t included TF Card)
HD 6mm Fix Lens
Pan Tilt Rotation, Horizontal:355° & Vertical:90°Ø
4pcs Array Infrared LEDs or 5pcs white supplement lights. 80m Night Vision
Support P2P, View & Anywhere & Anytime
Elegant Outline and Easy Installation
Provide Android & IOS APP (CamHi) and professional CMS PC client software
Wireless Protocols : 802.11b/g/n, 150Mbps, 10-50m
ABS Plastic + Metal Housing Material,Outdoor Use,Waterproof IP66
Built-in Microphone,Loud Speaker,Support Two Way Audio Talk Back
Microphone Effective Range 15 Meters, Loudspeaker Effective Range 60 Meters
The SD Card Slot Is Designed On The Camera’s Back Cover,Very Easy to Install the TF/Micro SD Card .
Specifications:
| Model | E5A-CAM-WIFI-2.0MP | |
| Camera | Operating system | Embedded Linux OS |
| Resolution | HD 1080P 2MP | |
| Megapixel | 1920*1080 | |
| Lens interface type | M12 | |
| Lens | 2.7-13.5mm Motorized Lens | |
| View angle | 60° | |
| Min.illumination | 0.05 Lux / 0 Lux(IR on) | |
| Day&Night mode | Auto IR-CUT | |
| Night vision distance | 4pcs Array Infrared LEDs or 5pcs white supplement lights. 60M Night Vision | |
| Video | Video compression standard | H.265/H.264 Main Profile/H.264 Baseline |
| Video streaming | Dual streaming | |
| Video resolution | First stream: 1080P(1920×1080), 720P(1280×720) | |
| Second stream: Q720P(640×480/640×352), | ||
| QQ720P(320×240/320×176) | ||
| JPEG stream :(Monitoring for mobile phones), | ||
| Q720P(640×352), QQ720P(320×176) | ||
| Video code rate | 32 to 8192Kbps. supports constant bitrate/variable bitrate | |
| Video frame rate | 18fps(PAL 50HZ). 20fps(NTSC 60HZ) | |
| Image settings | Brightness,saturation,contrast,Sharpness,Exposure,flip,mirror | |
| Image enhancement | Backlight compensation,Automatic white balance, | |
| Digital WDR, 3D digital noise reduction | ||
| Audio | Audio compression standard | G.726/G.711 |
| Audio code rate | Rate adaptive | |
| Audio Input | Support, Built-in Microphone | |
| Audio Output | Support Two Way Audio Talk , Built-in Loud Speaker | |
| Function | Motion detecting | Can set 4 independent detection region |
| (1-100 sensitivity can be set) | ||
| Alarm linkage | Alarm send pictures to the specified mailbox, | |
| alarm upload pictures and | ||
| videos to the FTP server, alarm write pictures and | ||
| videos to Micro SD card, alarm message push | ||
| Privacy mask | Maximum support 4 users to simultaneously browse | |
| OSD | Support camera name, date and time | |
| information superimposed | ||
| User management | Supports user and rights management | |
| Simultaneous viewers | maximum support 12 users to simultaneously browse | |
| (each stream supports 4 users) | ||
| Network protocol | TCP/IP,HTTP,TCP,ICMP,UDP,ARP,IGMP,SMTP,FTP, | |
| DHCP,DNS,DDNS,NTP,UPNP,RTSP etc. | ||
| Connection protocol | Support ONVIF 2.1(backward compatible) | |
| Wireless | Wireless standards | IEEE802.11b. 802.11g. 802.11n Draft |
| Frequency range | 2.4 GHz to 2.4835 GHz | |
| Wireless Security | 64/128-bit WEP. WPA/WPA2. WPA-PSK/WPA2-PSK. WPS | |
| Transmission rate | 11b: 11Mbps,11g :54Mbps,11n :135Mbps | |
| PTZ | Rotation angle | Horizon:0° to 355°. Vertical: 0° to 90° |
| Horizontal speed | 1° to 40°/S | |
| Vertical speed | 1° to 20°/S | |
| Preset | N/A | |
| Interface | Power interface | 1*5.5mm power interface |
| Ethernet | 1*RJ45 & Antenna 10M/100M Adaptive Ethernet Interface | |
| TF card Slot | 1*TF card slot. up to 64G(Don’t included TF Card) | |
| Reset button | Support | |
| General Specification |
Power supply | DC 12V 2A |
| power | Day: 3W; Night: 12W | |
| Operating temperature | -20 to +60 degree | |
| Operating humidity | 10% to 95% | |
| Material | ABS Plastic + Metal Housing ,Outdoor Use,Waterproof IP66 | |
| Installation | Rack mounting | |
| Size(W×D×H)(mm) | 175*115*110mm | |
| Weight(kg) | 2kg | |
| Package Size(W×D×H)(mm) | 250*250*100mm | |
| Package Weight(kg) | 2kg | |
| Type | Ip Camera |
|---|---|
| Style | PTZ camera |
| Resolution | 5MP |
