H.265 Waterproof P2p Security Bullet 8ch Ahd 1080p HD P/5MP CCTV Camera
Specification
|
Audio/video input |
video input
|
4CH
|
|
Video input signal type
|
BNC interface
|
|
|
Coaxial HD input
|
AHD:720P25 720P30
|
|
|
Analog input
|
CVBS
|
|
|
Network video input
|
When all analog channels are disabled, all 3 million
|
|
|
audio input
|
1CH，RCA interface （power：2.0Vp-p）
|
|
|
Audio/video input |
cvbs output
|
1CH，BNC interface
|
|
VGA output
|
1CH resolution: 1920*1080 (60Hz)
|
|
|
HDMI output
|
VGA HDMI
|
|
|
frequency output
|
1CH，RCA interface
|
|
|
Video audio coding parameters |
video compression standard
|
H.265
|
|
Video coding distribution rate
|
1080P
|
|
|
Video frame rate
|
1/16fps
|
|
|
Video bit rate
|
32kbps~6Mbps
|
|
|
Stream type
|
Composite streaming, video streaming
|
|
|
dual-stream
|
support
|
|
|
Audio compression standard
|
G.711u
|
|
|
Audio bit rate
|
64Kbs
|
|
|
Synchronous playback
|
4CH
|
|
|
HDD |
type
|
A SATA interface
|
|
capacity
|
Each supports a 6TB hard disk
|
|
|
The video management |
Video mode
|
Manual recording, timing recording, incident recording, motion detection recording, alarm recording
|
|
Playback modes
|
Instant playback, general playback, event playback, label playback, intelligent playback
|
|
|
Backup mode
|
Regular backup, event backup, video clip backup
|
|
|
peripheral interface |
Voice intercom input
|
1CH，RCA interface
|
|
network port
|
1 CH RJ45 10M/100M/1000M adaptive Ethernet port
|
|
|
USB
|
2CH
|
|
|
serial interface
|
1CH
|
|
|
else |
power supply
|
DC 12v
|
|
operating temperature
|
-10°C~+55°C
|
|
|
size
|
36.5*20.8*31.5
|
|
|
weight
|
3.7kg
|
|
|
power dissipation
|
under 10w
|
|
|
operating temperature
|
10~90
|
| Type | DVR |
|---|---|
| Style | BULLET CAMERA |
| Channels | 8ch + 2MP, 8ch + 5MP |
